|Machine Name:||SCEC Concrete Handling Equipment 1.6m3 Self Loading Concrete Mixer Truck Machine 8-12m3/hr||Water Supply System:||Water Supply System|
|Production Capacity:||1.6m3, 8-12m3 / Hr||Brake:||Pneumatic Brake, Double Independent Circuits|
|Diesel Engine:||Yuchai 4102 Supercharged Engine, 4-cylinder, 76KW / 2200rpm||Tires:||20.5/70-16|
|Diesel Tank:||100L||Hydraulic Tank:||140L|
cement handling equipment,
concrete mixer vehicle
Durable Concrete Handling Equipment 1.6m3 Self Loading Concrete Mixer Vehicle
SCEC Concrete Handling Equipment 1.6m3 Self Loading Concrete Mixer Truck Machine 8-12m3/hr
Introduction of SCEC 1.6m3 Self Loading Concrete Mixer Truck Machine Production 8-12m3/hr
Automatic loading and unloading mobile concrete mixer truck is a combination of the functions of a concrete transport truck and a concrete mixing station. It integrates concrete loading, metering, mixing, and discharging, and can realize the mixing of concrete transportation and onsite concrete construction operations Equipment, which is fast and efficient, greatly improves production efficiency and reduces production time and costs. It is suitable for concrete engineering construction in various special environments, crowded urban areas and remote areas.
Main components: 1 tank body 2 reducer 3 plunger motor 4 fuel tank 5 water pump motor 6 oil diffuser 7 engine 8 rear view camera 9 main pump 10 hydraulic oil tank 11 slewing support 12 swing bracket 13 water tank 14 tire 15 boom 16 Backhoe tank 17 Bucket 18 Tugboat 19 Brake / cylinder 20 Rear view mirror 21 Cab
Quick equipment introduction of SCEC 1.6m3 Self Loading Concrete Mixer Truck Machine Production 8-12m3/hr
Technical specification of SCEC 1.6m3 Self Loading Concrete Mixer Truck Machine Production 8-12m3/hr
The capacity of the drum is 2.6m3, the actual stirring volume is 1.6 square meters, the horizontal rotation is 270 °, and the height of the discharge port is 1.6 meters.
Water supply system: 2 * 300 liters, hydraulically driven self-priming water pump for feeding water, high pressure water pump for cleaning vehicles.
Production capacity: 1.6m3, 8-12m3 / hr
Brake: Pneumatic brake, double independent circuits
|diesel engine||Yuchai 4102 supercharged engine, 4-cylinder, 76KW / 2200rpm|
|Tires||Engineering machinery special tires20.5/70-16.|
|transfer method||Full hydraulic drive, 4 wheel drive, front wheel steering, domestic axle|
|Walking speed||0-10km / h at low speed, 0-30km / h at high speed|
|tank||Diesel tank 100L, hydraulic tank 140L|
|Cab||Left frame, anti-rollover, anti-falling type cab, front loading shovel|
|Hydraulic system||265 torque converter hydraulic system, open circuit, walking pump 40Mpa, displacement 90ml / r, walking motor 40Mpa displacement 63ml / r, stirring pump 40Mpa displacement 71ml / r, stirring motor 40Mpa displacement 63ml / r Mixing pump for hydraulic transmission and drum rotation|
|Joystick||Hydraulic four-position electric control lever measurement: electronic weighing, water meter, controlled recipe|
|Wheelbase of hydraulic gate||2m|
|Chute||Hydraulically adjust the angle to increase the discharge length, the chute can swing within 120.|
Features of SCEC 1.6m3 Self Loading Concrete Mixer Truck Machine Production 8-12m3/hr
1. High strength steel plate, enhance vehicle load capacity.
2. Small capacity mixing drum design, the angle is lower than same profession, effectively
reduce the gravity of vehicles , improve the driving safety.
3. Mixing blade with varying pitch design, and simplify the feeding device, ensure the speed
faster and mixing performance better.
4. Widely adopts the automatic welding, weld thickness reduction of nearly 15%, the vehicle
with high stability.
5. Using professional mature chassis, to ensure the vehicle with high-efficiency performance.
6. Focus on detail, humanized design, fully meet the personalized requirements of customers.
