Carbon Steel Long Cabin 16t Special Purpose Truck

Carbon Steel  Long Cabin 16t Special Purpose Truck
Carbon Steel  Long Cabin 16t Special Purpose Truck Carbon Steel  Long Cabin 16t Special Purpose Truck Carbon Steel  Long Cabin 16t Special Purpose Truck Carbon Steel  Long Cabin 16t Special Purpose Truck

Large Image :  Carbon Steel Long Cabin 16t Special Purpose Truck

Product Details:

Place of Origin: China
Brand Name: SCEC
Certification: ISO CCC
Model Number: ZZ1167M4611W

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Nude, Polished with wax before shipping on board
Delivery Time: Within 20 work days after receive order
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 units per month
Detailed Product Description
Product Name: 16t Hook Arm Garbage Truck Cabin: HW76 Long Cabin
Engine: 290/2200Hp/rpm Tire: 12.00R20
Overall Dimension(L*W*H)(mm): 6500×2300×1500 Tank Capacity: 16ton
Tank Material: Carbon Steel Max. Speed (km/h): 75
High Light:

sewer suction truck

,

refrigerated box truck

Special Purpose Truck 4x2 16t Hook Arm Garbage Truck 290hp Euro III



Introduction of Special Purpose Truck 4x2 16t Hook Arm Garbage Truck 290hp Euro III

16 tons hook arm garbage truck, also known as pull arm garbage truck and hook arm garbage truck

Hook-arm garbage trucks can be equipped with multiple garbage bins per vehicle, with high transfer efficiency and less environmental pollution, which is the development trend of urban sanitation. The operation is simple and convenient, and secondary pollution can be effectively avoided during the transportation of garbage.

The pull arm is our company's own brand Ove (OVO 16-ton telescopic sleeve arm, domestic well-known brand hydraulic double cylinder (bore 150)), three (four) electric control multi-way valve, domestic high pressure pump, standard roller rear leg , Wireless remote control + manual operation, reserved hydraulic quick connector interface of the trash bin, equipped with 10-15 cubic multifunctional bulk trash bin (hydraulic wingspan upper cover, hydraulic locking sealing back door) or 8-12 square conjoined compression trash bin ( Mobile garbage station).



Technical specification of Special Purpose Truck 4x2 16t Hook Arm Garbage Truck 290hp Euro III

Chassis Model ZZ1167M4611W
Cabin HW76 Long Cabin, with two seats and one bed, with Air Conditioner and electric window.



Engine

Model WD615.87
Horse Power (Hp/rpm) 290/2200, Euro II Emission Standard
Max.Toruqe(Nm/rpm) 1100/1100-1600
Displacement L

9.726



Type 6-cylinder in-line with water cooling, turbo charger and intercooling, 4-stroke direct injection diesel engine
Transmission HW19710, 10 speeds forward and 2 speeds reverse.
Front Axle HF7, Steering with double T-cross section beam, Loading Capacity: 9,000kgs
Driving Axle ST16, Pressed axle housing, central reduction with hub reduction, with differential locks between wheels and axles. ratio: 4.8. Option: 4.42
Suspension Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs, bogie spring and stabilizer
Steering System ZF8118, Hydraulic steering with power assistance
Brake System Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake
Tire 12.00R20
Fuel Tank Capacity (L) 300L Diesel Tank
Kurb Weight (kg) 9,200
Loading Capacity (kg) 10,800
Gross Vehicle Weight (kg) 20,000
Overall Dimension(L*W*H)(mm) 6500×2300×1500
Tank Capacity(L) 16ton
Tank Material Carbon Steel
Nos of Compartment 1
Wheelbase(mm) 4600
Max. Speed (km/h) 75

Carbon Steel  Long Cabin 16t Special Purpose Truck 0

Carbon Steel  Long Cabin 16t Special Purpose Truck 1

Carbon Steel  Long Cabin 16t Special Purpose Truck 2

Carbon Steel  Long Cabin 16t Special Purpose Truck 3

Carbon Steel  Long Cabin 16t Special Purpose Truck 4

Carbon Steel  Long Cabin 16t Special Purpose Truck 5



Packing & Delivery:

Nude package.

This model truck crane shipped by roro or bulk ship.



Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.



After-Sales Service
* Training how to instal and use the machine.
* Engineers available to service machinery overseas.
