| Machine Name: | XCMG 20t Telescopic Truck Crane XCT20L4 | Operating Weight: | 26020kg |
|---|---|---|---|
| Axle Load: | 6450/19570kg | Maximum Rated Total Lifting Capacity: | 20t |
| Minimum Rated Amplitude: | 3m | Engine: | SC7H260Q4/WP7.270.E434 192/2300kw/(r/min) |
| High Light: | telescoping boom crane,hydraulic mobile crane |
||
20t Telescopic Truck Crane U Shaped XCT20L4 Diesel Engine 192Kw Euro III
XCMG 20t Telescopic Truck Crane XCT20L4 Diesel Engine 192Kw Euro III
Features of XCMG 20t Telescopic Truck Crane XCT20L4 Diesel Engine 192Kw Euro III
• Four-section U-shaped new-type main boom, with a main boom length of 34m and a jib length of 8.3m, all lead the industry's highest level; the machine's lifting performance is the highest in the industry.
• Low-speed high-torque slewing system, adding dual-pump merging function, good micro-movement, and achieving telescopic and variable double-pump merging at the same time. The time has reached the industry-leading level.
• Crane intelligent boom control technology, automatic planning of lifting conditions, providing the most intelligent operation planning and operation safety protection, force limiter system, dangerous operation alarm to make operation safer, waterproof upgrade of the whole machine harness, mature supporting system This makes the whole machine more reliable; the electrical system of the relay is upgraded to a PLC control system, and with the new high-protection level wiring harness technology, a multi-pass wiring harness branch design is adopted, with fewer line branches, shielding fault points at the bottom, and high reliability.
• Car-level XCMG-machine interaction system, full ergonomic working space design, more reasonable button division, more friendly man-machine dialogue, and more comfortable operation.
Technical specification of XCMG 20t Telescopic Truck Crane XCT20L4 Diesel Engine 192Kw Euro III
| Item | unit | parameters |
| Model | XCT20L4 | |
| Size | ||
| Overall length | mm | 12535 |
| Overall width | mm | 2500 |
| Overall height | mm | 3420 |
| Wheelbase | mm | 4425+1350 |
| Track | mm | 2027 /1834 |
| Weight | ||
| Operating weight | kg | 26020 |
| Axle load | kg | 6450/19570 |
| Engine | ||
| Engine model | SC7H260Q4/WP7.270.E434 | |
| Engine rated power | kw/(r/min) | 192/2300199/2100 |
| Engine rated torque | N.m/(r/min) | 1000/1200~16001160/1200~1500 |
| Driving | ||
| Top speed | km/h | 85/80 |
| Minimum stable driving speed | km/h | 2~5 |
| Turning | ||
| Minimum turning diameter | m | 20 |
| Minimum turning diameter of boom | m | 24 |
| Maximum grade | ％ | 45/50 |
| Minimum ground clearance | mm | 261 |
| Approach angle | ° | 19/12 |
| Departure corner | ° | 13 |
| Braking distance | m | ≤10(speed 30km/h) |
| Fuel consumption per hundred kilometers | L | 30 |
| Main performance | ||
| Maximum rated total lifting capacity | t | 20 |
| Minimum rated amplitude | m | 3 |
| Lifting moment of basic boom | kN·m | 957 |
| Turntable radius | mm | 3425 |
| Outrigger | ||
| Vertical | m | 5.23 |
| Horizontal | m | 6.16 |
| Lifting height | ||
| Basic arm | m | 10.9 |
| Longest main arm | m | 34.5 |
| Longest main arm + jib | m | 42.8 |
| Longest main arm + jib + extension | m | - |
| Boom length | ||
| Basic arm | m | 10.6 |
| Longest main arm | m | 34 |
| Longest main arm + jib | m | 42.3 |
| Longest main arm + jib + extension | m | - |
| Working speed | ||
| Turning speed | r/min | 3 |
| Lifting speed | ||
| Main lifting mechanism | 135 | |
| Deputy lifting mechanism | 135 | |
| Boom extension time | ||
| Full extension | s | 50 |
| Full shrink | - | |
| Luffing time | ||
| Full arm | s | 35 |
| Full arm drop | s | - |
| Outriggers | ||
| Level | ||
| At the same time | s | 25 |
| At the same time | s | 23 |
| Vertical | ||
| At the same time | s | 25 |
| At the same time | s | 24 |
